Operational data |
Supply typ: | DC |
Maximum supply voltage: | 24 V |
Minimum supply voltage: | 8 V |
Supply voltage rating: | 12 V |
Maximum current consumption: | 470 mA |
Minimum current consumption: | 100 mA |
Current consumption rating: | 130 mA |
Maximum power: | 4 W |
Minimum power: | 0.8 W |
Power rating: | 1 W |
Minimum operating temperature: | -25 °C |
Maximum operating temperature: | 70 °C |
Maximum humidity: | 90 %rel |
IP code: | IP44 |
Suitable for unprotected outdoor area: | yes |
Suitable for protected outdoor area: | yes |
Display | |
Number of buttons: | |
Type of buttons: | |
Log memory: | |
Fingeranzahl: | 200 |
FAR: | 1:10 000 000 |
FRR: | 1:100 |
Recognition period: | 1 s |
Number of codes: | |
Codelänge max: | |
Kartenanzahl: | |
Lifetime in number of operations: | |
Lifetime in MTBF: | |
Line frequency: | |
Battery life in number of access instances: | |
Battery life when idle: | |
Efficiency: | |
Tolerance rated voltage: | 10% |
Maximum number of registration units: | |
Installed real-time clock: | |
Type of operation: | |
Minimum pin code length: | |
Signaling: | Visual |
FSuitable for RFID function: | |
Number of logs: | |
Electronic relays |
Switching function of electronic relay: | |
Number of electronic relays: | |
Switching voltage of electronic relay: | |
Switching current of electronic relay: | |
Leckstrom des elektronischen Relais: | |
Contact form of electronic relay: | |
Maximum impulse switching time of electronic relay: | |
Minimale Impulsschaltzeit des elektronischen Relais: | |
Short-circuit protection of electronic relay: | |
Overcurrent protection of electronic relay: | |
Type of switching voltage for electronic relay: | |
Mechanical relays |
Switching voltage of mechanical relay: | |
Switching current of mechanical relay: | |
Switching current of mechanical relay: | |
Contact form of mechanical relay: | |
Mechanical lifetime in switching cyclesh: | |
Electrical lifetime in switching cycles: | |
Maximum impulse switching time of mechanical relay: | |
Minimum impulse switching time of mechanical relay: | |
Short-circuit protection of mechanical relay: | |
Overcurrent protection of mechanical relay: | |
Spark quenching: | |
Switching function of mechanical relay: | |
Type of switching voltage for mechanical relay: | |
Cable transfer |
With housing:: | |
Maximum opening angle: | |
Cable length on the leaf side: | |
Pin on the leaf side: | |
Cable length on the frame side: | |
Pin on the frame side: | |
Cable shielding: | |
Number of data cable cores: | |
Core cross section of data cables: | |
Number of conductor cores: | |
Core cross section of conductors:: | |
Data cable rated voltage: | |
Data cable rated current: | |
Conductor rated voltage: | |
Conductor rated current: | |
Suitable for revolving door drive: | |
Number of door openings: | |
Separable when mounted: | |
Total number of cores: | |
