Datasheet

07.11.2024
Part n° 105103
Product name ekey home set IN BT micro 1 WH_EAV
Product name 2for Winkhaus blueMatic EAV
EAN code 9120068254779
Customs tariff number 8471 9000
Origin countryAT
Weight: 0.95 kg
Application area
Sales restriction

The ekey home Set with the finger scanner integra and a control panel micro for the motorized lock Winkhaus blueMatic EAV is used to idenjpgy authorized users and subsequently open building or apartment doors. The set is intended for use in both domestic and business applications. The ekey finger scanner integra is designed for fixed mounting in moving components such as door leaves or in immobile components, such as door frames, and for use in unprotected outdoor areas. The ekey control panel micro is designed for fixed mounting in moving components such as door leaves or in immobile components, such as door frames, and for use in protected indoor areas. To operate, you will also need a suitable power supply.
